Composing Room

The process of typesetting is called composition in the trade. Traditional composition has been called hot metal composition, which in some usage includes hand composition of foundry type since that was also cast once. For much of the history of printing, composition was hand composition of hand-cast type. Only in the 20th century were practical methods of machine setting invented, which leveraged on previous advances in machine casting of type.

Hot Metal Composition: Machine Composition

Monotype

The workhorse for book-work machine typesetting was the Lanston Monotype. It cast individual sorts as needed and assembled them at an assigned width. Once the page was “worked off,” the type could be melted to be cast anew, or it could be distributed into cases for hand composition or correcting of typographic errors matter set in the same face.

  • Composition casters with 160 cases of mats
  • Keyboards
  • Strip casters with 150 border mats
  • Sorts casters with 110 fonts of mats
Linotype

The original hot-metal composing machine for newspaper operations. In contrast to the Monotype, it cast whole lines at once. Typographic errors required the resetting and recasting of the entire line, and sometimes adjacent lines if the spacing was changed too much by the correction.

  • Model 1 (“X”) The Second Band Machine
  • Model 5
  • Model 31 (3)
  • Model 35 Comet (2)
  • Elektron Linotype
  • Linotype magazines in racks (115) liner, mat and parts storage
  • cabinets (17)
  • Linotype mats (300 fonts)
Linotype Teletypesetter

The Linotype was adapted to remote setting using transmission of wire-service copy with the Teletypesetter papr tape keyboard and printer.

  • Perforator keyboards (4)
  • Teletypesetter high-speed Punch
All Purpose Linotype

Merganthaler Linotype’s solution to the headline composition problem was the “APL,” a machine which would cast headline lines from hand-composed matrices. It had larger matrices than the largest regular Linotype, and with the Ludlow conversion composing sticks (2+), it could cast from Ludlow matrices.

lntertype (3)

Intertype was a clone of the Linotype, made to be able to interchange fonts and some parts, made by the Intertype Corporation.

  • Model C
  • Model C with Teletypesetter and Justape
  • Model F
  • 90 magazines in racks, all with mats
Linograph (1)

Linograph Model 1, with 5 magazines, 12 fonts of mats

Ludlow

The Ludlow was the main machine for headline composition. A compositor assembled matrices for one line of headline or display by hand on a “Ludlow composing stick.” Ludlow type is cast type-high like all other type, but it is not cast to the full point-size to that height; to save metal and expedite cooling (and thus cycling), all sizes are cast on a 12-pt slug, with massive cantilevers (far too solid to call kerns) hanging over the top & bottom, which are supported on high spacing slugs. The high spacing slugs were cast on Elrod casters, which could also cast low spaces; an Elrod in good condition could cast one-point leads.

  • Ludlows (2) — with 206 fonts of mats in 20-case racks
  • Ludlow Super-Finishers (2) support tools.
  • Elrods (2) with molds and support tools.
Unitype

The Unitype foundry-type typesetter set foundry type (harder than the normal hot-metal composing machines could cast on the fly). It requires specially cast foundry type that was notched for machine sorting (not unlike Linotype matrices). 10pt., with font.

General support equipment

A well equipped hot-metal composing room had a wide variety of specialized tools (in addition to a general machinery-shop for repairs!).

  • Typographical saws (5)
  • hand lead and slug cutters (12)
  • rotary mitering machines (3)
  • hand miters (3)
  • line-caster slug router
  • Monotabular broach
  • type-high gauges, dial (2)
  • small tools
  • Smelter – multiple pig mold, 8-pig, water cooled single pig molds (16)
  • pi trucks (8)
  • smelter tools

Hot Metal Composition: Hand composition

Hand type
  • 1700 cases of foundry type in 51 wooden and steel case stands, many with working tops
  • 400 case, 9,000-character, 10 pt. Chinese font
  • 2¼ tons of new foundry type in original wrappers
  • 90 fonts of wood type
  • quantities of decorative and antique type
  • large quantity of cuts (pictures, mounted plate or cast metal)
  • top of page ↑

Make-up and Correction

Imposition

After basic composition, type must be assembled into galleys for first proof and then “imposed” pages and multiple-page forms in preparation for printing. The table upon which the type is organized into one or multi-page forms is called the imposing stone, and often is made of marble. Later industrial models are precision steel. Marble and steel are preferred to ensure flatness and levelness of the surface when a form is prepared for the press. Forms are stored temporarily and long-term tied with page-cord (strong fine waxed string) on a galley in a galley rack. Forms that are going to or from the press for proofs or corrections will be stored in chases that fit the press, which are stored on edge in special racks and (in larger sizes) wheeled about on special “trucks” or dollies.

  • imposing stones, metal, over galley racks below (4)
  • imposing stone on wooden frame
  • furniture in racks. wood and metal
  • news chases (12)
  • chase trucks (6)
  • galleys 12×18, 2050
  • galleys 9×13, 1100
  • all in galley ranks, some will standing forms
  • Hamilton elevator storage rack, electric, 20-drawer news page size
Proofing

Small shops might take the galley proof with a brayer and plane and the page and final proofs on the production press, but larger shops installed presses especially adapted to quickly taking one or a few proofs for the author, editor, and proofreader.

  • Letterpress Proof Press
  • Vandercook model 1 (“rocker”) (2)
  • Vandercook Universal 1 (3)
  • Vandercook Electric proof dryer, rotary
  • Vandercook model 4
  • Poco hand press (2 sizes)
  • Wesel galley press electric
  • C&P galley press, hand
  • Vandercook model 30-26 4-color process in-line proof press, 26?
  • long 6 tons, with cabinet dryer
  • Vandercook Model 0
Stereotyping

For large (or repeated) runs of books or newspapers, neither hot-metal machine-composition type nor hand-composed foundry type is ideal. Having large quantities of type metal in standing forms is expensive inventory; also both kinds of type wear (machine comp wears faster than the harder foundry, but the wear on foundry is capital depreciation). In addition, only one press can print the result of one composition; to have multiple presses running hand comp would require multiple settings (and multiple errors and proofings). The solution to this problem is the stereotype (or in French, the cliché), by which each multi-page form, in a special chase, is cast into a solid thin metal plate, which may be printed either upon patent bases on standard presses or on rotary presses built for stereo plates. Multiple plates can thus be made from one setting (hence stereo); and once the plates are made, the type can be distributed or melted for reuse. Mats taken from the type form can be expressed to remote sites for casting, allowing coordinated advertising and syndicated copy without resetting.

  • flat mat casting boxes with pots (3) [Image: coarse screen]
  • Goss mat roller
  • Wood pony autoplates (2)
  • stereo pots (3) with hoods and pumps
  • mat scorchers, vacuum, flat (2) and curved (3)
  • curved plate gauge, pedestal mounted
  • curved plate routers (2)
  • flat plate router
  • flat plate shaver, rotary, with vacuum system
  • shell plate finisher
  • mat storage and conditioning boxes (2)
  • top of page ↑

Cold Composition

All means of composition not using cast metal type is cold composition. The typewriter was sneeringly called Cold Metal in some times and places (although you now hear it used for hand composers working at the case!) as well as Strike-on Comp; the various Zip-a-Tone/Letraset products have been called Rub-on Comp. In the middle of the Offset revolution, they were the low-end competitors to pulling reproduction proofs from metal type to produce camera ready art.

Phototypesetters

The primary replacement for Hot Metal were the phototype compositor machines. Here the photographic negative replaces the impress matrix casting new metal. Most were running-text machines as with most hot-metal. Most shops continued to handset headlines at the case or at the Ludlow to pull repro proofs, but the CG Headliner filled the niche of the Ludlow.

  • Berthold AG
  • Compugraphic (15)
  • Coxhead Headliner
  • Dymo (4)
  • Fairchild keyboard
  • Friden keyboard/printer
  • Intertype Fotosetter
  • Itek (4)
  • Kodak
  • Mergenthaler (12)
  • Monotype Monophoto
  • Morisawa
  • Photon (15)
  • Star (2)
  • Stripprinter (2)
  • Visual Graphics Photo Typositor
  • film processors
Phototypesetting computer

This computer accepted key-to-disk and key-to-tape input as well as OCR reading of typewritten input. The computer handled hyphenation and justification.

  • Digital Equipment Corp. (DEC) PDP 11/70
  • VDT input stations (7)
  • OCR reading machines (3)
  • input IBM typewriters (2)
  • magtape readers (2)
  • disk drives (4)
  • signal processors (4)
  • high-speed printers (4)
Composing Typewriters

Derogatorily called “Strike-on” composition, the composing typewriter was used for camera-ready copy in the quick-print business, in academic publishing, and small weeklies, where cost and turn-around were the driving factors. The best were capable of proportional spacing, justification, and handling multiple fonts. The familiar IBM Executive and Selectric can be considered to be in the low-end of this family; the IBM Composing Selectric was a computer-driven, auto-justifying, high-end system.

  • Friden Justowriters (2)
  • Varitypers (2) with 60 fonts
  • Densmore
  • Underwood
  • L.C.Smith
  • NCR
  • IBM Composing Selectric
  • top of page ↑

Photography & Plate-Making

Gallery Cameras

In the cold-type/offset world, plate-making is a photo-mechanical process, and that requires cameras big enough to make full-page size negatives.

  • Lanston Monotype overhead with carbon arc lamps
  • Klimsch 1180 with Ascorlux lamps
  • Clydesdale 402D with Macbeth lamps
Darkroom equipment

The gallery camera required a darkroom to develop the negatives and
to expose and develop the offset plates.

  • timers
  • safe lights
  • enlarger
  • exposure frames
  • Robertson 4½′×5½′, 2′×3′
Camera/Processors

Later, smaller cameras included built-in, semi-automatic darkrooms.

  • Itek Graphitek 430 (2)
  • Itek Positive Platemaker 77700
Platemaking
  • DuPont Dycril (plastic plate) exposure, etching, washout and dryer machines
  • Tabletop exposure machine, w/o vacuum
  • magnesium and zinc coating and etching machine with eye-fountain
  • engraver’s dragons blood fixing stove
  • reagent carboys (4)
  • top of page ↑
Digital Type

The Museum has recently acquired a couple of Macintosh Plus’s, initiating coverage of the new era in composition. Donations of a matching LaserWriter+, older Macs, or software to match would be most appreciated. Donations of current or intervening or prior digital type hardware and software would also be appreciated.

Pressroom

Letterpress presses (49 total)
Iron Hand Presses (6)
  • Adams acorn, Stansbury toggle, 13×16½
  • Hoe acorn, Stansbury toggle, 13×16½
  • Adams acorn, 22×28
  • Hoe 24½×27 “Washington”
  • Shniedewend 2×27 “Washington”
  • Wesel 20×27 “Washington”
Platen Job Presses
Tabletop (14)
  • Baltimore 2×3
  • Kelsey 5×8, 6×8, 6×10 (2).
  • Chandler and Price (C & P) Pilot 6×10.
  • Golding 5×8.
Floor model platens
Hand Fed (14)
  • Chandler and Price (C & P) 7×11, 8×12, 10×15, 12×18;
  • Colts Armory (Universal) 10×15;
  • Golding Pearl 7×11 (2), 9×14;
  • Golding 10×15, 12×18, 15×21;
  • Monitor 9×12;
  • Prouty 6.5×10, 9×13.
Automatic Feed Platens (5)
  • Chandler and Price (C & P) 10×15 with Rice feeder
  • C & P 10×15 with Miller feeder
  • C & P Craftsmen 14×22 with gold stamping attachments;
  • Heideiberg windmill 10×15:
  • British Thompson 10×15
Cylinder Presses (10 total)
Hand Fed (3)
  • Hoe drum cylinder, 34×44;
  • Meihle 25×38
  • Whitlock 26×35 (Last used at the old Hingham Journal.)
Automatic Fed (6)
  • Webendorfer-Wills Little Giant, 10×15
  • Miehle Vertical V36, 13½ x20 (2)
  • MAN, 17×22
  • Heidelberg KSBA 18×23
  • Kelly C. 20×27½
Web Fed (1)

(Roll-feed is called a web of paper.)

Goss Sextuple Straight-line curved stereo news press 1922, 62″ web, 22′ cutoff, 3- deck. 30 long, 12′ wide, 12′ tall. 45 tons: with automatic ink system, spare rollers and spare parts (3½ tons), with saddles for thin plate operation.

Offset (lithographic) presses (1)

The Museum will be interested in donations of Offset equipment.

Davidson 10×15 sheet-feed offset-litho press.

Engraving Presses

Mead “cannonball” steel engraving press
King copperplate engraving press 12 w. cylinder, 4′ diam. wheel;
DeMain, Kelton, and King copperplate engraving presses, 16 w. cylinder, 5′ diam. wheel.

Roto-Gravure

Speedy Gravure 6 Web single color, used in bandage packaging. Really small! Donated many years ago in situ, a Speedy Gravure 6 web press manufactured by the Champlain Gravure Company was moved into the Friends storage site several years ago. A larger gravure cylinder for a decorative border has been recently acquired.

Office Duplicators
  • Gammeter Multigraph
  • Multigraph composing machine w/ 11 cases Multigraph type in stand & Multigraph supplies and parts in fitted chest
  • Neostyle mimeograph, 1907
  • Gestetner mimeograph with 3 color fountains
  • Titan Rocket spirit duplicator, electric
  • top of page ↑

Bindery

Paper Cutters

(Hand powered unless specified)

  • 18″ table model
  • 20″ National
  • 22″ Challenge
  • 24″ Challenge
  • 24″ early vertical flywheel
  • 30″ Acme
  • 34″ National, Electric
  • Small bench scissors-type and roller-type cutters. Scrap paper baler.
Finishing
  • Spinit paper drill
  • electric Southworth round-cornering machine
  • Golding padding racks (2)
  • staplers, floor model (2)
  • table top saddle staplers (2)
  • sticher, electric
  • Hickok pen ruling machine with Baum pile feeder
  • Baum folder, 12×18″
  • Liberty Folder, 12×18″
  • Brehmer book signature sewing machine
  • VEB Building-in machine
  • bookbinder’s press 16×20
  • 45 cases brass bookbinder’s type
Mailing
  • Addressograph, floor model and desktop plate-makers (graphotypes), floor and desktop plate storage cabinets, 18-tray (6).
  • Elliott stencil-cutting typewriter
  • Dick’s hand mailer, brass
  • Saxmayer bundle tying machine, electric
  • top of page ↑

Support Apparatus

Display Materials
  • Glass dislay cabinets (3)
  • Friends’ promotional display
  • maquette of possible museum layout shop signs (4)
  • miniature pot-bellied stove
  • oak roll-top desk
  • time clock and time card racks
  • photo display of newspaper production in 8 36×78 framed panels
  • other art

Materials Handling

  • Forklift, Towmotor T30 LP gas powered, cap 3000 lbs. with 5′ forks and roll clamps for 2-high roll placement, 1970 hand pallet and skid jack trucks (4)
  • Forklift, Clark electric
Furniture
  • bookcases, wood
  • file cabinets, flat files (47 drawers)
